İSTA-BREEZE 1000 WATT 24 VOLT Rüzgar Türbini İ-1000 - En İyi Fiyat

CHARGING CONTROLLER CONNECTION ISSUES TO BE CONSIDERED!!!

one.        Mount the charger close to the battery and in a place that is not hot.

2.        Install the load resistor horizontally away from the battery and controller.

3.        First, connect the + ends of the battery and the charger, then the – ends, then connect the load resistor (resistor) to the load outputs and the 3 phase (ph) inputs from the last turbine.

4.        Check that the terminal connection screws are well tightened.

5.        Check that the charge controller inverter and battery pack are at the same volt.

6.        In order to stop the turbine manually, you can use a switch (63 k automaton or 3x25 on-off pako) between the wind turbine and the charge controller, which will reduce three phases if necessary.

7.        Be sure to ground the body of the pole.

8.        The length of the pole can be around 6-12 meters.

9.        You can mount the pole tightly with ropes from 3 sides against wind jerks.

10.    While the charger is connected to the system, do not drill anywhere on the device with a drill. If you are going to drill for assembly, the device must be in the off position.

CHARGER CONTROLLER IS NOT INCLUDED IN THE PRICE, YOU CAN BUY IT SEPARATELY FROM OUR PAGE.

iSTA Breeze® 1000 WATT 24 VOLT Wind Turbine i-1000

iSTA Breeze® i-1000 24 v 1200 Watt Land type wind generator It is preferred in chalets and summer houses wherever the usage area needs electricity. It provides charging current even at low wind speeds. Composite wings with aerodynamic structure have a durable strong structure. The original wind generator iSTABreeze i-1000 Extremely robust wind generator composite rotor blades of the last generation are very durable and robust and at the same time unusually light.

The body is equipped with cooling fins and is made of high-strength aluminum. The maintenance-free slip contact (without charcoal) guarantees a good current flow and therefore ensures that the cable is not twisted in the pole. Installation on pole pipe with cable connection. Required pole tube inner diameter: 37 mm nominal size! Other technical data is further in the description. This product has been successfully used 1000 times around the world! You can find matching charge controllers and poles in our store! It can also be used with photovoltaic solar cells with our 24 volt charge controller.

Teknovation Arge Bilişim Dan. Ltd. Sti. It was established by the Young Entrepreneur Electrical-Electronics Engineer Hamdin Bağçeci as a state-supported R&D company and continues its commercial activities in the field of Solar Electricity Generating Systems, increasing day by day with customer satisfaction.

In solar systems, we try to help our customers with the right product and the right price as much as possible.

A little warning to our customers. They should be careful about the unbranded, unlabeled Solar Panels removed from the power plants and the batteries that are trying to be sold as gel but are not real gel. We would like to share the information that such products are not allowed in our company. Of course, it is important to consider these when making price comparisons.
